Quick Details

  • Place of Origin: Guangdong, China (Mainland)
  • Brand Name: Ginleo
  • Model Number: ETA-1.5(No.11051)
  • Structure: Tube Heat Exchanger, Type A
  • Liquid Flow Rate: 1 m^3/h
  • Maximum Working Pressure: R:50 bar, W:8 bar
  • Certification: ROHS
  • Application: Evaporator
  • Shell: PVC
  • Tube: Pure titanium tube
  • Surface: covered sponge for insulation
  • Product No.: 11051

Packaging & Delivery

Packaging Details Wooden crates packing
Delivery Time 5~20days

Specifications

1,super strong corrosion proof ability
2,suitable for cooling:seawater
aquarium
salt solution
corrosive solution

Work Condition:
1)Refrigerant side(In the tube): R22,R134a,R407c,R410a
2)Water side (Between the tube and PVC shell):Nature water,sea water,salt solutionother  corrosive solution.

Material:
1)Heat transfer Tube: Thickness 0.6mm pure titanium tube.

2)shell: PVC.

Features:
1)capacity:12500BTU (3.75kw)--cooling

2)pure titanium tube has super strong corrosion proof ability and high intensity.

3) The seamless titanium tube was tested by 3.5MPa pressure precise Halogen Leak Detection to make sure the tube is strong and not leakage .

4)The PVC shell was tested by 0.5Mpa water pressure to make sure the water system not leakage .
5)It suitable for swimming pool heat pump,or heating some corrosive solution.

 Specification:



Model Ti TubediameterHeightconnection(mm)
KWBTU/hR Tonmmmmmmrefrigerationwater
ETA-0.331.03412.00.2812.7*0.55*25001103309.52,9.521"
ETA-0.51.34435.60.3712.7*0.55*40001103309.52,9.521"
ETA-0.751.96482.80.5412.7*0.55*60001604509.52,12.71.5"
ETA-12.58530.00.7112.7*0.55*75001604809.52,12.71.5"
ETA-1.53.7512795.01.0712.7*0.55*115001605909.52,12.71.5"
ETA-2517060.01.4212.7*0.55*150001606309.52,12.71.5"
ETA-37.525590.02.1319*0.5*1500025048012.7,15.881.5"
ETA-41034120.02.8419*0.5*2000025055012.7,15.881.5"
ETA-512.542650.03.5519*0.5*2500025058012.7,191.5"
ETA-7.518.563122.05.2625*0.5*2850031560012.7,192"
ETA-102585300.07.112-19*0.5*2500035564015.88,252"
ETA-1537.5127950.010.662-25*0.5*2850035579015.88,252"



Notice:The data list is our suggested data,We can produce any catacity heat exchagers according customer requirement and design
